D P Structure

D P Structure Specification

Product Type
Double Pole (D P) Structure

Material
Mild Steel

Capacity
11 kV / 22 kV / 33 kV

Output Power
Up to 500 kVA

Protection
Galvanized/Weather & Rust Resistant

Output Current
As per specification

Output Type
Outdoor

Current Waveform
AC Waveform

Application
Electrical Transmission & Distribution

Size
Standard

Dimension (L*W*H)
4000 mm x 3000 mm x 5000 mm (Approx.)

Color
Silver/Grey

About D P Structure

Our enterprise is a renowned entity in the domain, engrossed in manufacturing, exporting and supplying an extensive range of D P Structure. Offered structure is manufactured with high precision by utilizing the finest grade raw material in line with set industry norms. This structure is used in power and other allied industries for electric applications. Furthermore, this D P Structure is well proven for rapid assembly and available with us at market leading rates.

Features:

Rugged design
High tensile strength
Precise dimension
Corrosion resistance

D P Structure

We provide wide range of power substations structure which are extensively used in Power and Other Allied Industries. These are designed using latest and advanced technology and optimum quality of basic material. Offered at market leading prices these are in high demand among our clients owing to their features like reliability, durable in performance and fine finish. Before dispatching to the clients our products are checked under standard parameters to ensure maximum client satisfaction.

Durable Construction with Protection

Constructed from high-grade mild steel and treated with a galvanized finish, this D P Structure offers excellent protection against weathering and corrosion. Its robust build ensures longevity, even in challenging outdoor settings, which is essential for uninterrupted power transmission and distribution.

Versatile Performance for Power Networks

Designed to accommodate voltages of 11 kV, 22 kV, or 33 kV and output power of up to 500 kVA, the structure is highly adaptable for various transmission and distribution projects. The customizable output current and compatibility with AC waveforms make it suitable for numerous electrical grid applications.

Reliable Solutions from a Trusted Supplier

Manufactured, supplied, and traded from India, this D P Structure adheres to stringent quality standards. Clients benefit from the expertise of a recognized supplier network, ensuring timely procurement and installation for infrastructure development.

FAQs of D P Structure:

Q: How is the D P Structure utilized in electrical transmission and distribution?

A: The D P Structure is designed as a robust support system for overhead electrical lines, ensuring safe and efficient transmission and distribution of power, particularly at 11 kV, 22 kV, or 33 kV voltage levels.

Q: What are the main benefits of choosing a galvanized mild steel D P Structure?

A: Galvanized mild steel offers superior resistance to rust and weather, greatly enhancing the durability and lifespan of the structure, especially in outdoor environments exposed to harsh elements.

Q: When should this D P Structure be deployed in an electrical project?

A: It is most suitable for deployment during the installation or upgrading of substations, transmission lines, or distribution networks requiring reliable support for high-voltage equipment.

Q: Where can the D P Structure be installed?

A: This structure is engineered for outdoor use and can be installed at substations, power distribution points, and other key locations in electrical infrastructure projects across India.

Q: What is the manufacturing process for the D P Structure?

A: The process includes precise fabrication of mild steel components, followed by hot-dip galvanization to ensure corrosion resistance, and then assembly according to specified dimensions and standards.

Q: How does this D P Structure accommodate output power and current requirements?

A: The structure is built to support output power up to 500 kVA and can be tailored to meet specific output current specifications, ensuring compatibility with various transmission system configurations.
