Insulator .

Insulator . Specification

Overheating Protection
YES

Power Factor
>0.99

Surface Finish
Glazed

Efficiency
99%

Mounting Type
Horizontal or Vertical

Operating Temperature
-40C to +80C

IP Rating
IP54

Shape
Disc

Insulation Material
Porcelain

Feature
High Dielectric Strength, Weather Resistant

Humidity %
95%

Connector Type
Bolt/Clamp

Product Type
Insulator

Application
Used for providing safe earthing in electrical systems

Protection Level
Other

Frequency (MHz)
50 Hertz (HZ)

Rated Voltage
125 kV

Color
Brown

Dimension (L*W*H)
110 mm x 90 mm x 90 mm

Weight
2-15 Kilograms (kg)

Size
Standard

Phase
Single Phase

Input Voltage
Up to 11 kV

No Of Poles
Single Pole

Material
Porcelain

Connection Type
Clamp Mount

Arc Resistance
High

Corrosion Resistance
Yes

Flame Retardant
Yes

Creepage Distance
320 mm

UV Resistance
Yes

Mechanical Strength
10 kN

Insulator . Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
10 Pieces Per Week

Delivery Time
1-2 Week

Main Export Market(s)
Western Europe, Australia, North America, South America, Eastern Europe, Middle East, Africa, Central America, Asia

Main Domestic Market
All India

About Insulator .

Insulator

Available with us wide variety of Industrial Insulators which is manufactured using high quality basic basic material procured from reliable vendors. The latest technology and the machinery used in the entire process ensure its high utility to the clients. These insulators are capable of withstanding voltage for a considerable amount of time without any difficulty. The features like efficient and sturdy performance, dimensional accuracy have made our products popular among our customers.

Robust Mechanical and Electrical Performance

Engineered with a 10 kN mechanical strength and a creepage distance of 320 mm, this porcelain insulator provides secure and stable support for single-phase power distribution. Its high dielectric strength and 125 kV rated voltage safeguard against electrical breakdown, making it ideal for high-voltage environments.

Superior Durability and Environmental Resistance

The insulator's porcelain material, UV resistance, flame retardant design, and glazed finish offer unmatched durability in extreme weather conditions. It performs reliably between -40C and +80C, resists up to 95% humidity, and holds an IP54 rating, ensuring excellent protection even outdoors.

Versatile Application and Easy Installation

Designed for single-pole and single-phase systems, this insulator is suitable for safe earthing in electrical substations and transmissions. Its clamp/bolt mounting options and horizontal or vertical installation mean flexibility across various settings, making it a practical solution for manufacturers, suppliers, and traders.

FAQ's of Insulator .:

Q: How is this porcelain insulator installed in a power system?

A: The insulator can be mounted using clamp or bolt connections and is suitable for both horizontal and vertical installations. It's typically fixed to support structures in electrical substations or transmission lines to ensure safe earthing and electrical isolation.

Q: What makes this insulator suitable for outdoor environments?

A: Its glazed porcelain surface, high arc and UV resistance, corrosion-proof design, and IP54 rating enable optimal performance in harsh weather. The insulator withstands temperature variations from -40C to +80C and humidity up to 95%, making it highly reliable outdoors.

Q: When should I use this specific insulator model?

A: Use this insulator for applications requiring high mechanical strength, flame resistance, and voltage handling up to 125 kV. It's ideal for single-phase earthing in power stations, utilities, and industrial electrical systems.

Q: Where is this insulator typically applied?

A: This insulator is commonly used in power transmission and distribution networks, particularly in substations and areas where robust insulation and reliable earthing are essential for system safety and efficiency.

Q: What are the main benefits of using this insulator?

A: Key benefits include high dielectric and mechanical strength, resistance to environmental and electrical hazards, long service life due to the glazed porcelain finish, and straightforward installation in various settings. Its efficiency ensures minimal energy loss.

Q: How does the insulator ensure safety in electrical systems?

A: By providing a long creepage distance (320 mm) and high insulation resistance, it minimizes leakage currents, prevents flashovers, and ensures safe earthing, protecting both equipment and personnel from electrical faults.
